REFRIGERATION PLANTS ELECTRIC COMPONENTS AND FAULTS TRAINING SYSTEM MODEL : LI-RFENT04

Description

Specifications Of Electric Components and Faults Training System Model:

Body Material:

• Electric components and faults training system model is Steel Frame Structure
• Digital Thermal Printed Sheet
• Acrylic Round support board or Plastic Sheet

Working area:

• Working area: 60*40*15 cm
• Frame size: 100 * 65 *15 cm
Safety Circuit Breaker
• Operating voltage: 440V.
• Cutting power (Icn): 10000A (10kA) (Ics-75% icn).
• Characteristic curve: C.
• Mechanical life: 20000 operations.
• Electrical life: 10000 operations.
• Earth-Leakage Protection.
• Auto Short-Circuit Management
• ERR Tripping sense Current 20mA

Compressor of Electric Components and Faults Training System Model:

• Power: 1/2HP,
• Single-phase 220V
• Control Box

Main Contractor:

• 2 x 3NO, 1NC. 3 x 4NO.
• Model Number: mentioned by the bidder
• Supply Type: AC
• Number of Pole: 4
• Phase: Single
• Main Circuit Rating Voltage: 220V
• Main Circuit Rating Current: 1A
• Switch Voltage Rating: 1000V
• Switch Current Rating: 23A

Main Power Switch:

• Switch Type: Rocker 2 Pole
• Model Number: mentioned by the bidder
• Max. Current: 15A
• Max. Voltage: 250VAC
• Mechanical Life: 10000 Cycles
• Type: Rocker Switch
• Product name: KCD4-101N
• Rating: 10A/250VAC
• Product type: ON OFF4PIN 30A250vac 35A 125vac
rocker switch hy12
• Usage: Extensive Use
• Function: ON-OFF

Automatic Fuse:

• Model Number: mentioned by the bidder
• Switch Type: Thermal
• Breaking Capacity: High
• Product name: RY Thermal Temperature Fuse
• Electrical Rating: AC-250V 10A; AC-125V 16A
• Open temperature: 65-260°C
• Reset temperature: NA
• Life Times: One time
• Used for: Temperature control for household electric
appliances

Start-up capacitor:

• Model Number: mentioned by the bidder
• Type: Polypropylene Film Capacitor
• Supplier Type: Original manufacturer, ODM, Agency,
Retailer
• Capacitance: 1-100UF
• Tolerance: ±5%
• Package Type: Through Hole
• Rated Voltage: 200-500V
• Operating Temperature: -40°C-85°C
• Capacitance Range: 2-100UF
• Application: Washers, Motor, Pump
• Certificate: CE UL TUV CQC VDE BIS
• Color: White and Black
• Shape: Round
• Package: 50-100 PCS/CTN
• Operation temperature: 40/85/21

Start-up relay:

• Model Number: mentioned by the bidder
• Voltage: 12V
• Rated Current: 200A
• Car Make: Universal
• Contact Form: 1H(SPST-NO)
• Contact Material: AgSnO2
• Contact Rating (resistive):
• 200A/14VDC

• Max. Switching Volt: 280VDC
• Max. Switching Current: 20A
• Contact Resistance: ≤30mΩ
• Coil Voltage (Max.): 230VDC

Overheat Protection (Bimetallic):

• Model Number: mentioned by the bidder
• Product name: KSD301/HC301 Prevent Dry Thermostat
• Material: Metal
• Life Cycle: 100000
• Switch Type: Closed
• Temperature range: 30-150C
• Terminal’s size: 16*16*12mm

Cooling Fan:

• Model Number: mentioned by the bidder
• Type: Axial Flow Fan, Ventilation Fan
• Electric Current Type: AC
• Mounting: FREE STANDING
• Blade Material: Plastic
• Bearing Type: Sleeve/Ball Bearing
• Voltage: 220V
• Material: PBT Plastic

Chamber Indoor lamp:

• Model Number: mentioned by the bidder
• Item Type: Refrigerator Lamps
• Lamp Luminous Efficiency(lm/w): 20
• Light Source: LED
• Input Voltage(V): 24V, 60V, 100V-130V, 220V-240V
• Lamp Power(W): 1
• Lamp Luminous Flux(lm): 20-100 lm
• CRI (Ra>): 70%
• Color Temperature (CCT): Warm White
• Working Temperature (): (-40 to100) 0C
• Working Lifetime (Hour): 50000

AC Panel Meter:

• Measurement accuracy: 1%
• Measuring range: AC voltage: AC80-300V, AC current:
0.1-100A
• Power consumption: 0.2VA
• Measuring speed: about 2 times per second
• Overall dimensions: 70 * 40 * 39mm
• Installation size: 68 * 38mm (embedded installation)
• The instrument is only suitable for pure AC 50-60HZ
of the mains power

Digital Multimeter:

• Model Number: mentioned by the bidder
• Measuring Current Range: DC Current 2mA~10A
• Measuring Voltage Range: 10V~600V
• Measuring Resistance Range: 1000Ω~60MΩ
• Measuring Capacitance Range: NO
• Measuring Inductance Range: NO
• Operating Temperature: 0~40
• Dimensions: 147*71*45mm
• Product Name: Multi-meter
• Color: Black +Blue
• display: 1999 Counts LCD Display
• DC current: 2mA/20mA/200mA/10A
• AC voltage: 200V/600V
• DC voltage: 200mV/2V/20V/200V/600V
• Resistance: 200/2K/200K/2M/20M
• Auto power-off: 15 minutes no operation auto
power-off
• On and off test: Buzzer and light

Accessories Of Electric Components and Faults Training System Model :

Experimental Manual : 1copy
Connecting Cord : 1 Set.
And other related Standard accessories.

Others:

Brand : Labinnova
Country Of Origin: China
Manufacturing : Assemble In Bangladesh
Training 5 Days
Warranty: One Year.
